Accuenergy AcuRev 2020-1EM-WEB-E Multi-Circuit Power/Energy Meter, 9 circuits, 333 mV CT input, Ethernet/WiFi/RS485, external display

Model: AcuRev 2020-1EM-WEB-E | Order No: AcuRev-2020-1EM-WEB-E

Accuenergy AcuRev 2020-1EM-WEB-E Multi-Circuit Power/Energy Meter, 9 circuits, 333 mV CT input, Ethernet/WiFi/RS485, external display-

Downloads: datasheet manual

Accuenergy AcuRev 2020-1EM-WEB-E Multi-Circuit Power/Energy Meter, 9 circuits, 333 mV CT input, Ethernet/WiFi/RS485, external display

Model: AcuRev 2020-1EM-WEB-E | Order No: AcuRev-2020-1EM-WEB-E

Multi-circuit power and energy meter that monitors 9 single-phase circuits with external 333 mV CT input, features Ethernet, WiFi and RS485 communications and external remote display.

Multi-circuit power and energy meter that monitors 9 single-phase circuits with external 333 mV CT input, features Ethernet, WiFi and RS485 communications and external remote display.

Discontinued!

This product has been discontinued and is no longer available.

There is no direct replacement, however we recommend the:

Accuenergy AcuRev 2110-mA-WEB2 Multi-Function Power Meter with SnapOn CT, 80 and 100 mA input, dual ethernet-

Accuenergy AcuRev 2110-mA-WEB2 Multi-Function Power Meter with SnapOn CT, 80 and 100 mA input, dual ethernet

Model: AcuRev 2110-mA-WEB2

Compact and robust, the multi-function power meter with SnapOn CT is designed to measure up to 18 single-phase or 6 three-phase circuits. It has dual ethernet and current input of 80 and 100 mA. It performs real-time metering, measures energy consumption, multi-tariff time-of-use (TOU), and monitors power quality.

Learn More

Accuenergy AcuRev 2110-mV-WEB2 Multi-Function Power Meter with SnapOn CT, 333 mV and Rogowski coil input, dual ethernet-

Accuenergy AcuRev 2110-mV-WEB2 Multi-Function Power Meter with SnapOn CT, 333 mV and Rogowski coil input, dual ethernet

Model: AcuRev 2110-mV-WEB2

Compact and robust, the multi-function power meter with SnapOn CT is designed to measure up to 18 single-phase or 6 three-phase circuits. It has dual ethernet and current input of 333 mV and Rogowski coil. It performs real-time metering, measures energy consumption, multi-tariff time-of-use (TOU), and monitors power quality.

Learn More

Not what you're looking for? Let’s do a search and help you find what you need.

Recommended Accessories

Accuenergy AcuCT-125-400:333 Split Core Current Transformer, 1.25 x 1.25", 400 A:333 mV-

Accuenergy AcuCT-125-400:333 Split Core Current Transformer, 1.25 x 1.25", 400 A:333 mV

AcuCT-125-400:333

Accuenergy AcuCT-200-600:333 Split Core Current Transformer, 2 x 2", 600 A:333 mV-

Accuenergy AcuCT-200-600:333 Split Core Current Transformer, 2 x 2", 600 A:333 mV

AcuCT-200-600:333

Accuenergy AcuCT-200-1200:333 Split Core Current Transformer, 2 x 2", 1200 A:333 mV-

Accuenergy AcuCT-200-1200:333 Split Core Current Transformer, 2 x 2", 1200 A:333 mV

AcuCT-200-1200:333

Accuenergy AcuRev 2020-1EM-WEB-E Offers

The AcuRev 2020-1EM-WEB-E multi-circuit, multifunction power and energy meter is a revenue-grade digital meter engineered for multi-tenant kWh metering and high-density electrical metering.

Features

  • Revenue grade standard ANSI C12.20 Class 0.5 and IEC 62053-22 Class 0.5s
  • Real-time RMS metering: line and phase voltage, current for each circuit
  • Monitors up to 9 circuits/channels/tenants in a single unit
  • Energy: Active (kWh), Reactive (kVAR) and Apparent (kVA)
  • Power and Power Factor: Active (P), Reactive (Q), Apparent (S), Power Factor
  • Demand and peak demand: power and current demand for total and each circuit
  • 10-690Vac direct voltage input, fits all voltage rating system with one model
  • Multi-tariff Time of Use (TOU) can be used according to different regional billing requirements
  • Monitors power quality parameters such as voltage and current THD, individual voltage and current harmonics up to 31st order, voltage crest factor, current K factor, voltage and current unbalance

  • Direct voltage measurement of up to 690Vac L-L/400Vac L-N for electrical distribution systems
  • Real-time energy metering, power quality and I/O data can be stored in non-volatile onboard memory (8MB)
  • Free cloud-based metering data storage (4GB)
  • Over/under limit alarms for demand control
  • Built with 8 digital inputs (DI), and 2 digital outputs (DO) to easily integrate other metering data and control in a single unit
  • Wide range in power supply thus no control transformer is required
  • Serial via Modbus RS485, Modbus via Ethernet, Wi-Fi, BACnet IP, I/O, and infrared communications
  • External 333mV current transformer input option provides the perfect solution for retrofit projects
  • External remote display

Applications

  • Tenant sub-metering
  • Energy efficiency studies
  • Building/facility management
  • Branch circuit monitoring
  • Panel metering

Benefits

  • Accurate energy reading for billing for multiple tenants
  • Verify utility bills to avoid overcharge by using revenue grade and accurate meters
  • Identify cost-saving opportunities by viewing the complete picture of energy usage, with detailed consumption historical trending data down to each circuit
  • Identify high demand window and locate saving opportunities

Functions

Accuenergy AcuRev 2000 Series Specifications

Parameter Accuracy (± %rdg.) Range
Active Energy 0.5% 0 to 0 to 999,999kWh
Voltage 0.5% 10V to 400V
Current 0.5% 5mA to 10,000A
Active Power 0.5% 4000.0kW
Reactive Power 0.5% 4000.0kvar
Apparent Power 0.5% 4000.0kVA
Power Factor 0.5% -1.000 to 1.000
Frequency 0.2% 45 to 65Hz
Power Demand 0.5% 4000.0kW
Current Demand 0.5% 5mA to 10,000A
Harmonic 1% 0 to 100%
Unbalance 1% 0 to 100%
Meter Running Time 0 to 999,999.9
Digital Input
Input Style Dry Node
Input current (MAX) 2mA
Input Voltage Range 15~30V
Start Voltage 12V
Stop Voltage 10V
Pulse Frequency (MAX) 100Hz, 50% duty cycle
SOE Resolution 2ms
Auxiliary Power of DI
Output Voltage 24VDC
Rated Power 1W
Voltage Input
Nominal Full Scale 400Vac L-N, 690Vac L-L
Withstand 1500Vac continuous, 2500Vac, 50/60Hz for 1 minute
Input Impedance 2MΩ per phase
Metering Frequency 45Hz~65Hz
PT Burden <0.2VA
MODELS 1EM 2EM 1DM 2DM
Typical Application Retrofit sub-metering and branch circuit monitoring Retrofit branch circuit system monitoring New distribution panel with up to 80A circuits per phase New distribution panel with up to 80A circuits per phase
Single Phase 1 Hot Circuits Monitored 9 18 9 18
Single Phase 2 Hot Circuits Monitored 3 6 3 6
Three-Phase Circuits Monitored 3 6 3 6
Additional Current Transformers Required Yes Yes No No
Current Metering Via 333mV Output Current Transformers Via 333mV Output Current Transformers 20-80A Direct Input 20-80A Direct Input
Dimensions Including Meter 8.15 x 4.15 x 3.06" (207 x 105.4 x 77.7mm) 10.39 x 4.15 x 3.06" (264 x 105.4 x 77.7mm) 11.54 x 4.15 x 3.06" (293 x 105.4 x 77.7mm) 17.56 x 4.15 x 3.06" (446 x 105.4 x 77.7mm)
Click here for complete specifications on the Accuenergy AcuRev 2020-1EM-WEB-E

What's included with the Accuenergy AcuRev 2020-1EM-WEB-E

  • Accuenergy AcuRev 2020-1EM-WEB-E Multi-Circuit Power/Energy Meter, 9 circuits, 333 mV CT input, Ethernet/WiFi/RS485, external display
datasheet for the Accuenergy AcuRev 2020-1EM-WEB-E Multi-Circuit Power/Energy Meter, 9 circuits, 333 mV CT input, Ethernet/WiFi/RS485, external display manual for the Accuenergy AcuRev 2020-1EM-WEB-E Multi-Circuit Power/Energy Meter, 9 circuits, 333 mV CT input, Ethernet/WiFi/RS485, external display

Accessories

Click on a category to view a selection of compatible accessories with the Accuenergy AcuRev 2020-1EM-WEB-E Multi-Circuit Power/Energy Meter, 9 circuits, 333 mV CT input, Ethernet/WiFi/RS485, external display.

Accuenergy AcuCT-125-400:333 Split Core Current Transformer, 1.25 x 1.25", 400 A:333 mV AcuCT-125-400:333
Conventional split core current transformer features a 333 mV low voltage output for safe opening, a window size of 1.25 x 1.25", and current input of 400 A.
$43.24 USD

was $47.00


Learn More
Accuenergy AcuCT-200-600:333 Split Core Current Transformer, 2 x 2", 600 A:333 mV AcuCT-200-600:333
Conventional split core current transformer features a 333 mV low voltage output for safe opening, a window size of 2 x 2", and current input of 600 A.
$52.44 USD

was $57.00


Learn More
Accuenergy AcuCT-200-1200:333 Split Core Current Transformer, 2 x 2", 1200 A:333 mV AcuCT-200-1200:333
Conventional split core current transformer features a 333 mV low voltage output for safe opening, a window size of 2 x 2", and current input of 1200 A.
$52.44 USD

was $57.00


Learn More
