EED Watts Up .Net Internet Enabled Plug In Power Meter with Remote Reporting and Switching
- ethernet enabled
- remote plug control
- datalogging
Part Number:
EED WU-NET
In Stock?
Yes! Available up to 14 units Quantity
Price:
$247.75
CAD (change)
CAD (change)
Shipping Information:
Ships in 1-2 Days
Arrives:
Arrives:
Sep 14-
Sep 16
Max of 14 unitsSep 16
$9.95 or FREE
for orders of $350
for orders of $350
Fast: Ships today*
Arrives:
Arrives:
Sep 09-
Sep 14
Max of 14 unitsSep 14
$14.95
Fastest: Overnight
Arrives:
Arrives:
Sep 07
Max of 14 units
$59.95
Meet the new extraordinarily powerful addition to the product family. With all the capabilities of the PRO, the Watts Up? .Net goes even further. Internet enabled and power switching!
Ideal for remote monitoring, the built-in web server allows data to be accessed via the internet. Connect the meter to the public internet (via home or office network) and the meter will automatically output data. Create a free account on the manufacturers website (instructions included in the box) to access the data from your meter. You'll be able to see all the data. Connect a wireless router into the meter's ethernet port, and the meter can be used wirelessly.
In addition, the Watts Up? .Net introduces active energy savings. With an internal switching relay, the Watts Up? .Net can turn off power to the end load based on user configurable rules.
These rules and their associated application include:
The Watts Up? .Net is also available with 4 times the memory with a purchase of 50 meters or more at one time. It is ideal for applications requiring logging for long periods of time.
APPLICATIONS:
Ideal for remote monitoring, the built-in web server allows data to be accessed via the internet. Connect the meter to the public internet (via home or office network) and the meter will automatically output data. Create a free account on the manufacturers website (instructions included in the box) to access the data from your meter. You'll be able to see all the data. Connect a wireless router into the meter's ethernet port, and the meter can be used wirelessly.
In addition, the Watts Up? .Net introduces active energy savings. With an internal switching relay, the Watts Up? .Net can turn off power to the end load based on user configurable rules.
These rules and their associated application include:
- Time of day Effective when your utility has TOU (time of use) rates, where they charge a higher rate during peak times
- Peak usage (watts) For commercial accounts, which are typically charged a surcharge if their consumption ever surpasses a peak threshold during the billing month. Having multiple Watts Up? .Net meters can enable you to simply and economically "shed power" and keep you under the threshold.
- Cumulative usage (wh) Use for tiered pricing rates, when higher usage is billed at a higher rate.
- Manual on/off For security reasons, rebooting servers, or while on vacation.
The Watts Up? .Net is also available with 4 times the memory with a purchase of 50 meters or more at one time. It is ideal for applications requiring logging for long periods of time.
APPLICATIONS:
- Design Engineers
- Lab Technicians
- Development Engineers
- Electronic Enthusiasts
- Test Engineers
- Manufacturing Compliance
- IT/MIS Professionals
- Facilities / maintenance
- Energy management
- Home automation
The Good:
The Bad:
The Bottom Line:
The Bad:
The Bottom Line:
Full Review
- Ethernet connection
- Internet enabled (embedded web server, TCP/IP, IP addressable)
- Power switching
- NIST calibration certifcate
- Real-time logging capable
- Records stored in internal memory (over 8000 records, over 120000 if just watts). Additional memory available.
- PC interface, software included.
- User selectable and automatic interval setting
- 18 values displayed
- Cost displayed
- 1.5% accuracy
- World-wide compatibility (universal outlet version)
- 120 v, 60 Hz, 15 amps
- Higher ratings of 100-250v, 50/60Hz, and 15 amps require the universal outlet (UO) version. The electronics in the meter are capable of 20 amps but the cord and receptacle have different ratings. Verify the rating on the cordset you are purchasing.
- +/- 1.5%, + 3 counts of the displayed value
- Below 60 watts, amps and power factor lose accuracy
- Ethernet connection includes communication via TCP/IP, and http.
- Power switching rated at 100,000 cycles and is normally on
- NIST calibration certificates available
- USB interface
- Mains supply voltage fluctuations not to exceed +/- 10% of the nominal voltage
- Rate can be entered from $0.001 to $85.00 per kilowatt hour, in tenths of a penny
- Input is via 6' electric cord (USA style only), output is via outlet on top of meter
- Indoor use only
- Dimensions: 7" x 4" x 2" (18cm x 10cm x 5cm)
- Weight: 2.5 lbs (1 kg)
- UL listed to standard UL 610010-1, and CAN CAS/C22.2 61010-1
- UO version also CE marked
- UL certification requires the following statement:
- Altitude up to 2000 meters
- Temperature 5°C to 40°C
- Maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50% relative humidity at 40°C
- Installation Category II
The EED Watts Up .Net software automatically graphs all the data and includes an integrated analysis tool, called the Payback Calculator, which automatically calculates the time required for a new energy efficient appliance to pay for itself. Monthly savings are calculated, and they are compared to the purchase price of the new appliance. The data and graphs can also be exported to popular spreadsheet and word processor programs for further analysis.
Any of the 19 parameters can be recorded. The inerval can be selected from as fast as one second. There are 3 memory modes:
(Mac users are encouraged to use the new .Net model, since the user interface is browser based).
Works with Peak Software's Energy Guard Google Gadget
Energy Guard is a commercial real-time energy monitoring and control platform that also provides direct integration with building automation systems and allows users to view live consumption information on the Web and in iGoogle™ using PEAK Software's EnergyGuard™ Google Gadget.
Any of the 19 parameters can be recorded. The inerval can be selected from as fast as one second. There are 3 memory modes:
- Automatic: the meter will log forever. The interval starts at one second. When the memory fills, every other record is deleted and the interval doubles. When the memory fills again, every other record is again deleted and the interval doubles. For example, the interval would be 1 second, then 2 seconds, then 4, then 8, then 16, etc).
- Stop: the meter stops logging when the memory is full
- Overwrite: the meter will log forever, an overwrite the data in memory in a first in, first out mode.
(Mac users are encouraged to use the new .Net model, since the user interface is browser based).
Works with Peak Software's Energy Guard Google Gadget
Energy Guard is a commercial real-time energy monitoring and control platform that also provides direct integration with building automation systems and allows users to view live consumption information on the Web and in iGoogle™ using PEAK Software's EnergyGuard™ Google Gadget.
