TED Pro Home Energy Monitor

Model: TED PRO HOME

For residential and small business applications. The TED Pro Home energy monitoring system allows you to monitor energy usage through awareness of ongoing consumption and cost.

$299.95 USD

9 in Stock



TED Pro Home

Home energy monitoring system.

What is TED Pro Home?

TED Pro Home is a state-of-the-art system for use in residential, commercial and government buildings and small industrial complexes. The system allows you to monitor energy usage through awareness of ongoing consumption and cost. With availalbe countertop display, desktop applications and mobile apps your energy use and alerts can be presented in real time. While coloured LEDs alert the user to rate-tier changes, high demand, cost or other user-defined parameters.

The system can also be configured to automatically adjust thermostat settings or turn off loads based on user-selectable criteria such as cost of electricity, total use, cost, time of day, budget, or request from a utility or electric provider.

The system is designed to work on any single or three phase electrical system anywhere in the world and is compatible with numerous energy or demand-rate billing systems, including fixed, time-of-use, step/tiered, seasonal, demand, or any combination of those mentioned. The system also accommodates taxes, fixed charges and fuel surcharges to accurately reflect the monthly electric bill.

Included

The basic system consists of an MTU and an ECC

TED Pro Home MTU

The measuring transmitting unit (MTU) measures the energy consumption, demand voltage, current, and power factor. MTU Pro is designed for 3-phase systems in small to medium size commercial, institutional and industrial environments. It is suitable for any 3-phase system up to 1200A, 600V.

The MTU is generally located at the main electrical panel and transmits the information collected, over the building's existing electrical wiring, using state-of-the-art Power Line Carrier communications (PLC) to an ECC which receives and interprets the data. Multiple MTUs can be used to give individual measurement of panels or loads. For systems with solar, wind or other generation, multiple MTUs will tell the user consumption, generation and net, from-or-to the utility.

TED Pro Home ECC

The energy control centre (ECC) is the communication hub for the system. It receives raw energy-use data from the MTU(s), interprets the data and calculates the current energy cost, cost today, month-to-date, and various other calculations. The ECC can be configured to communicate with display devices, computers, networks, mobile devices, thermostats, and load control devices via Ethernet, PLC, WiFi, ZigBee, USB, or XBee. Your TED system can be further configured to send text or e-mail alerts using TED Advisor software.

Multiple ECCs in multiple locations can be monitored via the internet using TED's proprietary AggreData software.

Go Further with TED Pro Home with these Options:

  • Multiple MTUs can be added to separately measure various loads or generation.
  • Multiple systems can be used and the data aggregated at a central location.
  • Display Devices
    • Wired-in Display connects directly to ECC.
    • Optional Wireless Display with battery backup can be mounted anywhere or carried around for load checking.
  • Communication Modules. ECC includes two USNAP ports and one USB port.
    • WiFi modules - Allow wireless communication with a router or other WiFi-enabled device.
    • ZigBee modules - Allows communication with Smart Meters, Smart Thermostats and other ZigBeeenabled devices.
  • Smart Thermostats
    • WiFi or ZigBee-based

TED Pro Home Features

  • Designed for homes with breaker panels up to 400 amps.
  • Features advanced, state-of-the-art Powerline Carrier Communication:
    • Easier setup and improved performance
    • Smooth, reliable communication over existing powerlines
  • Ability to monitor up to 32 individual circuits with TED Spyder. Track usage and monitor individual rooms/circuits.
  • Features a NEW Energy Control Centre (ECC):
    • Embedded with new version of Footprints data-logging Software
    • Customizable graphing (data ranges and colours)
    • USNAP expandable
    • Displays power factor
  • Ability to send data to multiple third party applications
  • Multiple Display options (wired & wireless Display available)

Measuring Transmitting Units (MTU)
Types of Services
Single-phase 2-Wire or 3-Wire Yes
3-phase 4-Wire Wye No
3-phase 3-Wire Delta No
3-phase 4-Wire Hi-leg Delta No
Frequency 50/60 Hz
Maximum Voltage - Phase/Phase n/a
Maximum Voltage - Phase/Neutral 240 V
Minimum Voltage 95 V
Maximum Current - per phase 400A *
Maximum Wire Size 4/0 AWG (15mm OD)
Voltage Measurement Voltage Divider Circuit
Current Measurement 200A:1.5V Split-Core CTs
Operating Temperature -40°C<TA>+50°C
Energy Measurement and Calculations Cirrus CS5461A
Overall Accuracy Better than ± 2% **
Measure and Transmit Energy ± 1W
Measure and Transmit Demand ± 1VA
Measure and Transmit Voltage ± 0.1V
Measure and Transmit Phase Currents ± 0.01A
Measure and Transmit Power Factor ± 0.1%
Communication Interface PLC
PLC System Yitran IT700 System

* Will measure up to 400A with two parallel 200A using additional CT set or with optional 400A CT set

** From 1.5% to 100% of Full Scale

Data-Receiving Unit
Works w/ 3-phase & single phase MTU Yes
Maximum Voltage Phase/Neutral 277 V
Minimum Voltage Phase/Neutral 95 V
Frequency 50/60 Hz
Cord Types Available UL / EU / UK / AU
Operating Temperature +5°C<TA<+40°C
Communication Methods Available PLC, Ethernet, Wifi, ZigBee, USB, XBee
USB 2.0 Port 1
USNAP 2.0 Port 2
Display Port 1
Compatible w/ ZigBee SE 2.0 smart meter Yes
Accept Demand Reduction Request from Utility Yes
Maximum number of MTUs on one system 4
Maximum number of Spyders on one system 4
Maximum number of Load Measured 36
Power-on LED Blue
Link Status LED Green / Yellow
Transmit / Receive Green / Red
Energy-Use Indicator Bar Green / Yellow / Red
Software
TED Footprints™ - Historical, Graphical, Profiling, TED Advisor, Aggredata Included
TED Smart Load-Shedding Software Included
System and Utility Rate Setup Wizard Setup
Solar / Wind Generation
Display System Load Yes
Display System Generation Yes
Display Net Metering Yes
Data Display Options
Computer - TED Footprints™ Software Yes
Desktop LCD Display Yes
Wireless LCD Display Yes
Mobile Phones or Pads Yes
AggreData - Aggregates data from multiple systems Yes
Third Party Applications Yes
Data Storage / Display
Second Data Every second for 2 hours
Minute Data Every minute for 48 hours
Hour Data Every hour for 90 days
Day Data Every day for 2 years
Month Data Every month for 24 years
Rate Structures
Rates downloadable from Internet Yes
Rates can be pre-programmed Yes
Number of TOU Rates 4
Number of Tier/Step Rates 4
Critical Peak Rates Yes
Weekend Rates Yes
Holiday Rates (US and Canada) Yes
Seasonal Rates (4 seasons) Yes
Tier/Step within Seasons Yes
Tier/Step within TOU periods Yes
TOU Rates within Seasons Yes
Demand Charges or Demand Penalties Yes
Number of House Codes Unlimited
Update Time 1 Second
Optional Devices / Equipment
Wireless Display with Backlight/Battery Yes
Smart Thermostats Wifi or ZigBee
USNAP Modules Yes - 2 (Wifi or ZigBee)
USB Dongle Wifi or ZigBee
Load Shedding Devices 20A 1P PLC, Wifi, or ZB
Load Shedding Devices 40A 2P PLC, Wifi, or ZB
Click here for complete specifications on the TED TED PRO HOME

Accessories

Click on a category to view a selection of compatible accessories with the TED Pro Home Energy Monitor.

Spyder Individual Circuit Monitoring Tool for TED Pro Home SPYDER 60 20018
The Spyder is a monitoring unit that comes with eight (8) Current Transformer donuts that go around individual circuit conductors inside your breaker panel to gather data for individual circuits.
$149.95 USD

Learn More

TED Wired Display Wired Display 20016
This product is an optional wired backlit display for TED PRO HOME.
$69.00 USD

Learn More

TED Wireless Display Wireless Display 20023
TED Wireless Display for use with TED Pro Home. Includes USNAP and its wireless from ECC.
$149.95 USD

Learn More

TED Pro Home 200amp MTU/CT Set MTU/CT ADD-ON 20017
Add on kit to an existing TED Pro Home package. This set includes one Measuring Transmitting Unit (MTU) and 2 Current Transformers (CTs). Designed to monitor an additional main breaker panel, subpanel, or wind/solar installation up to 200 Amps. Works with a TED Pro Home system only.
$149.95 USD

Learn More
