AccuEnergy AcuCT-3050-2000:333 AC Split Core Current Transformer, 2000A:333mV, 3 x 5"
Downloads:
datasheet



AccuEnergy AcuCT-3050-2000:333 AC Split Core Current Transformer, 2000A:333mV, 3 x 5"

Model: AcuCT-3050-2000:333

Compact and light-weight conventional split core 333mV current transformer. Designed for general panel/device monitoring. Features a window size of 3 x 5". Has a Current Input of 2000A and Output of 333mV.

$75.00 USD

2 to 3 Weeks


AccuEnergy AcuCT 333mV Series Offers

Compatible with any 333mV output current transformer for low cost energy efficiency and energy management systems.

Features

  • Premium press-to-open current transformers
  • Conventional split-core style CT
  • Safe mV secondary output
  • 0.5% accuracy from 10 to 120% of rated current
  • UL recognized

AccuEnergy AcuCT-3050-2000:333 Specifications

Input Ranges 40A to 2000A
Rated Option 333mV
Window Sizes 3 x 5" (76.2 x 127mm)
Exterior Dimensions 5.748 x 7.5 x 1.402" (146 x 190.5 x 35.6mm)
Accuracy  0.5%
Standard/Certifications UR, CE, RoHS
Form Factor Rectangle Split Core
Click here for complete specifications on the Accuenergy AcuCT-3050-2000:333
