Fluke VR1710 Voltage Quality Recorder

Model: VR1710

The new Fluke VR1710 Voltage Quality Recorder is an ideal tool for single phase power quality troubleshooting and preventative maintenance applications.

$1,099.99 USD

7 to 8 Weeks



Fluke VR1710 Offers

Features

  • Continuous recording of all values with no gaps Save testing time by getting the whole picture with one instrument that records both events and voltage
  • Clear graphical summary of data and quick overview of key power quality parameters Take the guesswork out of diagnosing voltage quality problems
  • Min, Max, and Average RMS values (1/4 cycle) with time stamp Quickly see what happened and when
  • Actual transient display (>100 Ωs) with time stamp Identify power quality issues quickly with included graphical software
  • Flicker recording to EN 61000-4-15, individual harmonic and THD values with trends Easily identify if the problem is power quality or equipment related
  • Statistical analysis of single phase voltage events - Reduces analysis time by tracking event quantities and magnitudes
  • Includes PowerLog software package for quick download, analysis, and automatic reporting Save time by generating power quality reports automatically with pre-set templates

Specifications

  • Operating voltage: 70 V to 300 V
  • Min/Max/Avg RMS value: Resolution 0.125 V
  • Number of events: 175,000
  • Time resolution: 5 ms
  • Voltage resolution: 0.125 V
  • Harmonics measurement: EN 61000-4-7 (up to 32nd)
  • Flicker measurement: EN 61000-4-15
  • Number of recording channels: 1 Phase to Neutral; 2 Phase/Neutral to Ground
  • Recording time: 1 day to 339 days depending on average time from 1 second to 20 minutes
  • Frequency range: 50 Hz ± 1 Hz and 60 Hz ± 1 Hz
  • Safety category rating: CAT II 300 V
